Tri-Flex Loop®

The safest and most reliable means of absorbing up to 24" of movement resulting from thermal changes, random seismic shifts, and misalignment in a piping system. It also dampens vibration and reduces the transmission of noise. Tri-Flex Loops are designed to be pressure tested 1.5 times their maximum rated working pressure and manufactured with a 4:1 safety factor. The Tri-Flex Loop® eliminates the need for the added installation expense of traditional long length pipe loops and its compact design saves valuable space.

Tri-Flex Loops do not impose additional thrust loads on the piping system and thus eliminate the need for costly anchoring or thrust blocks while also eliminating pipe guides required by traditional pipe designs such as expansion pipe loops or expansion joints.

Want to learn more about expansion loop movements and how to implement this product in your application? Try our free VisualLoop App today!

Details
Documentation & Brochures
BIM Content
Submittals
Function

Flex-Hose Co.'s Tri-Flex Loop® makes a world of difference in critical piping connections. It is designed to provide a superior flexible pipe loop that will absorb and compensate multi-plane pipe movements simultaneously as well as reduce piping stress.

Materials

Stainless Steel or Bronze (other alloys and styles available)

Sizes

1/2" to 14" I.D. (Stock sizes 1/2" to 4")

Notes

Working pressure of standard hose and braid construction up to 1325PSI or full vacuum and operating temperatures of -400° F to +1500° F.

Warranty

Flex-Hose Co. offers a free 5-year warranty to show their confidence and back the Tri-Flex Loop® 100%.
